Link Shortener Pt. 2 - Using Routers, Handlebars and Making a Simple FrontEnd

So, in my previous post we created an express backend to shorten a given URL via http get and post requests. But, handling http requests is not possible for everyone. So, today we will be making a frontend for our app. We will be using handlebars to make the frontend. Using handlebars let us avoid the CORS issue.

To start with, I highly recommend to read my previous post or to start with my initial github repo.

Sanitizing our app.js

Currently, our app.js looks messy and unorganized. So, let's just organize it a little bit. Let's create a new folder in the root of the project named routers. In this folder we can keep our router files which will make our code for view routes and api routes separate. For that, in the project root I created a new folder named routes. There I create api.js. There, at first I Imported express. Then I initialized the router component by calling express.Router(). After this, we need to export the router by using module.exports = router.

After this we will need to configure the router to receive get and post request as we did with app(const app = express(); app.get()...) in app.js in the previous post.

So, I brought in all the api related routes i.e. /api/create POST request and /api/all GET request, and assigned them with this router in api.js. After that rearrangement the code looks something like this:

router.get("/all", (req, res) => {
  db.find({}, (err, docs) => {
    if (!err) {
      res.send(docs);
    } else {
      res.status(500).send({
        err
      });
    }
  });
});

router.post("/create", (req, res) => {
  if (req.body.URL) {
    let URL = req.body.URL;
    if (
      /^(?:(?:(?:https?|ftp):)?\/\/)(?:\S+(?::\S*)?@)?(?:(?!(?:10|127)(?:\.\d{1,3}){3})(?!(?:169\.254|192\.168)(?:\.\d{1,3}){2})(?!172\.(?:1[6-9]|2\d|3[0-1])(?:\.\d{1,3}){2})(?:[1-9]\d?|1\d\d|2[01]\d|22[0-3])(?:\.(?:1?\d{1,2}|2[0-4]\d|25[0-5])){2}(?:\.(?:[1-9]\d?|1\d\d|2[0-4]\d|25[0-4]))|(?:(?:[a-z\u00a1-\uffff0-9]-*)*[a-z\u00a1-\uffff0-9]+)(?:\.(?:[a-z\u00a1-\uffff0-9]-*)*[a-z\u00a1-\uffff0-9]+)*(?:\.(?:[a-z\u00a1-\uffff]{2,})))(?::\d{2,5})?(?:[/?#]\S*)?$/i.test(
        URL
      )
    ) {
      db.findOne(
        {
          URL: req.body.URL
        },
        (err, fndURL) => {
          if (err) {
            res.status(500).send({
              err
            });
          } else {
            if (!fndURL) {
              let ID = shortid.generate();
              let shortenedLink = baseURL + "/api/" + ID;
              let URLobject = {
                ID,
                URL: req.body.URL,
                shortened_url: shortenedLink
              };
              db.insert(URLobject, (err, newObj) => {
                if (!err) {
                  res.status(201).send(newObj);
                } else {
                  res.status(500).send({
                    err
                  });
                }
              });
            } else {
              res.status(201).send(fndURL);
            }
          }
        }
      );
    } else
      res.status(400).send({
        msg: "Invalid URL passed"
      });
  } else {
    res.status(400).send({
      msg: "NO URL passed"
    });
  }
});

router.get("/:id", (req, res) => {
  db.findOne(
    {
      ID: req.params.id
    },
    (err, doc) => {
      if (err) {
        res.status(500).send({
          err
        });
      } else {
        res.redirect(doc.URL);
      }
    }
  );
});

You can notice that I removed the /api part from my route string, as that will be handled in the app.js(scroll a little bit down to find out how). I brought in the GET request to "/:id" to here as it was causing some problems while sitting in the root.

Now the problem is, this piece of code depends on the connection to our nedb database. But our main app also needs access to that database as well. So, it will be wise to move that database connection code to a completely separate file. So in the project root I created a db_connect.js file and pasted this code there:

const nedb = require("nedb");
const db = new nedb({
    filename: "./URLData.db"
});
db.loadDatabase(err => {
    if (!err) {
        console.log("db found/created successfully");
    } else {
        console.log(err);
    }
});

module.exports = db;

At the end of this code the database was exported so that I can require that db variable in other files.

Back to api.js where I bring in the shortid package and the database like this:

const shortid = require("shortid");
const db = require("../db_connect");

Now, if you notice carefully, there is a need of the baseURL variable here. But we don't have the port set in this file, that's set in app.js. So, the solution I came up with was to use the PORT variable from the environment variables. For that, I installed a package named dotenv:

npm i dotenv

After this I needed to create a .env file in the root of the project where I declared the PORT variable:

PORT=2020

So, now defining the baseURL variable was really easy. I had to just initialize dotenv like so:

require("dotenv").config();

and declare baseURL like so:

const baseURL = process.env.baseURL || `http://localhost:${process.env.PORT}`;

So the api.js finally looked like this:

require("dotenv").config();
const express = require("express");
const shortid = require("shortid");

const router = express.Router();

const db = require("../db_connect");

const baseURL = process.env.baseURL || `http://localhost:${process.env.PORT}`;

router.get("/all", (req, res) => {
  db.find({}, (err, docs) => {
    if (!err) {
      res.send(docs);
    } else {
      res.status(500).send({
        err
      });
    }
  });
});

router.post("/create", (req, res) => {
  if (req.body.URL) {
    let URL = req.body.URL;
    if (
      /^(?:(?:(?:https?|ftp):)?\/\/)(?:\S+(?::\S*)?@)?(?:(?!(?:10|127)(?:\.\d{1,3}){3})(?!(?:169\.254|192\.168)(?:\.\d{1,3}){2})(?!172\.(?:1[6-9]|2\d|3[0-1])(?:\.\d{1,3}){2})(?:[1-9]\d?|1\d\d|2[01]\d|22[0-3])(?:\.(?:1?\d{1,2}|2[0-4]\d|25[0-5])){2}(?:\.(?:[1-9]\d?|1\d\d|2[0-4]\d|25[0-4]))|(?:(?:[a-z\u00a1-\uffff0-9]-*)*[a-z\u00a1-\uffff0-9]+)(?:\.(?:[a-z\u00a1-\uffff0-9]-*)*[a-z\u00a1-\uffff0-9]+)*(?:\.(?:[a-z\u00a1-\uffff]{2,})))(?::\d{2,5})?(?:[/?#]\S*)?$/i.test(
        URL
      )
    ) {
      db.findOne(
        {
          URL: req.body.URL
        },
        (err, fndURL) => {
          if (err) {
            res.status(500).send({
              err
            });
          } else {
            if (!fndURL) {
              let ID = shortid.generate();
              let shortenedLink = baseURL + "/api/" + ID;
              let URLobject = {
                ID,
                URL: req.body.URL,
                shortened_url: shortenedLink
              };
              db.insert(URLobject, (err, newObj) => {
                if (!err) {
                  res.status(201).send(newObj);
                } else {
                  res.status(500).send({
                    err
                  });
                }
              });
            } else {
              res.status(201).send(fndURL);
            }
          }
        }
      );
    } else
      res.status(400).send({
        msg: "Invalid URL passed"
      });
  } else {
    res.status(400).send({
      msg: "NO URL passed"
    });
  }
});

router.get("/:id", (req, res) => {
  db.findOne(
    {
      ID: req.params.id
    },
    (err, doc) => {
      if (err) {
        res.status(500).send({
          err
        });
      } else {
        res.redirect(doc.URL);
      }
    }
  );
});

module.exports = router;

Now you will be wondering what will happen in app.js now. So for that here is the updated app.js:

require("dotenv").config();
const express = require("express");
const apiRoutes = require("./routes/api");

const app = express();

const PORT = process.env.PORT;

app.use(express.json());

app.use("/api", apiRoutes);

app.get("/", (req, res) => {
  res.send("Hello World");
});


app.listen(PORT, () => {
  console.log(`Server running on port ${PORT}`);
});

So, here the first noticeable change is: dotenv was initialized and the PORT variable was set to process.env.PORT, instead of process.env.PORT || 2020.

Another change is that, all the code related to handling '/api/___' was removed. Now as they are now handled by router exported from api.js so we imported api.js like so:

const apiRoutes = require("./routes/api");

and asked our app.js to use this apiRoutes for any request to '/api/':

app.use("/api", apiRoutes);

and the final change in this file is to remove all the database connection code, as we don't need that here anymore.

Now if you run the app, your app will run the same as it was running.

Setting up Handlebars and showing our first page

Installing handlebars is really easy -

npm i express-handlebars

Now in app.js we will need to initialize handlebars, and it is done like so:

const hbs = require("express-handlebars");

app.engine(
  "hbs",
  hbs({
    extname: "hbs",
    defaultLayout: "default",
    layoutsDir: __dirname + "/views/layouts/",
    partialsDir: __dirname + "/views/partials/"
  })
);
app.set("view engine", "hbs");

What this piece of code is doing is that it is bringing in the express-handlebars package and then storing it as hbs. In the next line, the app engine is set to "hbs", and the second parameter is the initialization of hbs with an object mentioning the extname(extension name, here set as hbs), defaultLayout(the default layout to use while rendering the pages, here set to use default.hbs), layoutsDir(directory to find the layouts) and partialsDir(directory for the partials). Now this "hbs" engine is set to be the "view engine" in the next line.

Now let's render our first handlebars page. Remember, in previous post, we showed a response of normal text saying "Hello World". Let's now render a handlebars page instead of that. But before that, let's configure our views folder.

The folder structure of views look something like this:

  • views
    • layouts (it is for the layout files)
      • default.hbs (the default layout configured)
    • partials (for storing the partial files like footer)
    • home.hbs (the file which will be later responsible for the view shown in '/')

Now, the basic HTML stuff is to be done in the default layout, which will be used by all the other layouts. It is to ensure the principle of coding: write once, use everywhere

So, I configured the default.hbs like this:

<!DOCTYPE html>
<html lang="en">

<head>
    <meta charset="UTF-8">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <meta http-equiv="X-UA-Compatible" content="ie=edge">
    <title>Shorten URL App</title>
</head>

<body>
    {{{body}}}
</body>

</html>

Now, I set the home.hbs to show hello world in h1 tag:

<h1>Hello World</h1>

Now it was the time to show this page instead of the hello world shown in <pre> tags. That is really easy, we just need to use the render function instead of send function:

app.get("/", (req, res) => {
  res.render("home");
});

This will render the home.hbs.

Now I want to include a style file. But in express, we need to first define static folder to do so. For that, using this piece of code will be enough:

app.use("/static", express.static("public"));

Now let's create a public folder in the project root and in that folder let's have a style.css file in it.

In that file, for now, we will reset the margin and padding and set the box sizing to border box and set the font family to something cool:

* {
    margin: 0;
    padding: 0;
    box-sizing: border-box;
    font-family: 'Gill Sans', 'Gill Sans MT', Calibri, 'Trebuchet MS', sans-serif;
}

To link the css in our layout used this code:

<link rel="stylesheet" href="/static/style.css">

And now the page looks like this:

Now let's make our form to create the shortened link.

Creating the form and sending POST request via Fetch API to create shortened links

I changed up the markup of the homepage to include a form at this point. The markup now looks like this:

<div class="container">
    <h1>URL Shortener</h1>

    <form>
        <input type="text" name="URL" id="URL" placeholder="enter thee URL"/>
        <input type="submit" value="Generate shortened link">
    </form>

    <div>
        <a href="" id="shortenLink"></a>
        <p id="error"></p>
    </div>
</div>

Now, to handle the submission of this form I included a script in this file in script tags:

<script>
    document.querySelector("form").addEventListener("submit", async (e) => {
        e.preventDefault();
        URL = document.getElementById("URL").value
        shortenLinkP = document.getElementById("shortenLink")
        errorP = document.getElementById("error")
        data = {
            URL
        }
        const response = await fetch("/api/create", {
            method: 'POST',
            headers: {
                'Content-Type': 'application/json'
            },
            body: JSON.stringify(data)
        })
        const res_json = await response.json()
        if (!res_json.msg) {
            shortenLinkP.innerText = res_json.shortened_url
            shortenLinkP.href = res_json.shortened_url
            errorP.innerText = ""
        }
        else {
            errorP.innerText = res_json.msg
            shortenLinkP.innerText = ""
        }
    })
</script>

Here, at first, I query selected the form and added an eventListener to listen to the submit event. The asynchronous(async) callback function was passed with a parameter e denoting the event. So in the function, at first the default behavior of the form submitting to itself was prevented - e.preventDefault();. After that we had to get the value of the URL input in the input field with the id of URL(URL = document.getElementById("URL").value).

After this I selected the paragraphs, one for showing the shortened URLs and another one for showing the errors returned error from the server. After this, the data object was created with the URL value. Then we used fetch API to send a POST request to our "/api/create" with the request type set to POST, the body set to stringified version of the data object and header set to show that JSON data was sent. If you want to know more about Fetch API, read here.

After this we awaited to convert the response to json object and stored it in res_json.

If you have read the previous post then you will know that if the response from server contained a msg property then there was some error. Otherwise, there was the shortened link sent back. So we did just that, by checking if there was a msg property in res_json. If there was, then the errorP was updated with the error. Otherwise the shortenLinkP was updated with the link in both href and the text. I also made sure that error and the shortened link don't show up together.

The UI was looking a bit bad so I added some CSS.

* {
    margin: 0;
    padding: 0;
    box-sizing: border-box;
    font-family: 'Gill Sans', 'Gill Sans MT', Calibri, 'Trebuchet MS', sans-serif;
}

.container {
    max-width: 500px;
    width: 90vw;
    margin: 20px auto;
    text-align: center;
}

input {
    display: block;
    width: 70%;
    padding: 10px 20px;
    margin: 10px auto;
}

input[type="submit"]:hover {
    cursor: pointer;
}

#error {
    color: red;
    font-weight: bold;
}

The final app now looks like this:

Hosting

With some documentation set in the HTML view, I will be hosting this app really soon, will mention that in the comments. The final code is in GitHub Here

Conclusion

There are still some ways, in which the frontend of the app can be improved. The most obvious two choices will be:

  1. Showing all the shortened URL in the homepage. For doing this it will be better to store the name of the webpages with their URLs

  2. Handling the form input errors in client side. It is not always good to rely on the server to send the errors, there should be some client side verifications as well

It will be nice if anyone can create the versions with the updates I mentioned and comment it down for others to see.
